Max. SPL @ 10 % THD 128 dB half space (70 Hz â 12 kHz averaged)Max. SPL Peak @ 10 % THD 135 dB half spaceFrequency response +/-3 dB 70 Hz â 12 kHzFrequency response -10 dB 55 Hz â 19 kHzPower amp output (RMS/Peak) 600 / 1,200 WAmplifier type Class D â bi-ampedLow/mid speaker 1 x 12", 2.5" voice coilHF driver 1", 1.7" voice coilHorn characteristics 60° x 40° CD horn, rotatableActive x-over frequency 1.6 kHz FIR X-over with 72 dB/oct.Maximum input level 20 dBuAnalogue inputs 1 x XLR combo balancedAnalogue Thru 1 x XLR balancedDSP-Out 1 x XLR balancedNetwork port EtherCON RJ45, 1 x InFilter presets Flat, Boost, Low Cut, RemoteRemote software DSP CONTROL (Windows, Mac OS)DSP functions Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, MuteSample rate 48 kHzSystem latency Less than 2 msMains connection 1x IEC connector with V-Lock securing system, 100-240 VPower consumption 1 A / 100â240 V nominal according to EN 62368-1Pole mount DuoTilt 3°/7°Rigging points 3x M8 (AP-8)Carrying handles 2 x MultiGripHousing Hybrid (birch multiplex/MDF)Surface Black acrylic enamelFront grille 2 mm metal grille backed with black acoustic foamDimensions (WxHxD) 37 x 67 x 36.5 cm 14-9/16 x 26-3/8 x 14-3/8"Weight 21.9 kg / 48.28 lbs
